A tapered insulation system is a method of providing effective thermal insulation and reliable drainage for a new build or roof refurbishment project. It comprises a series of bespoke components which combine to create the required insulation performance and drainage falls.
STRATEX is offered as a single-layer tapered insulation system. Carefully manufactured components are bonded together in factory conditions to form a bespoke solution. These are supplied ready to fit as a single scheme equivalent to the actual roof area and are simply installed as per the agreed plan and secured to the roof deck.

Unlike our STRATEX single-layer system, with a multi-layer system multiple components laid over flat ‘packer’ boards are bonded together, layer by layer, on-site. The total surface area to be bonded can be up to three times greater than the actual roof area. This can create increased time and cost penalties.

Contact us for more information

Product advantages KEMPERTHERM Tapered Insulation

Compatible with KEMPEROL liquid waterproofing membranes (including use in green roofs)

Less time required to install

Lower overall material and labour costs

No bonding between layers required on-site

Components

KEMPERTHERM Insulation

  • KEMPERTHERM T is a flat-edged board, factory tapered to falls of 1:40, 1:60, 1:80 or 1:120 as specified. Individual boards are supplied clearly marked as a complete system to each bespoke roof design.
  • KEMPERTHERM TR is the tapered board system with additional reinforcement to the top face.e.

KEMPERSHIELD Vapour Barrier
This reinforced aluminium, self-adhesive vapour barrier is Class 'O' rated and is suitable for concrete, profiled metal or concrete decks.

KEMPERFIX Adhesive and Fixings
A range of fully compatible adhesive and fixings for either mechanical or adhesive bonding of the insulation board to the substrate.

KEMPEROL Waterproofing
STRATEX can be specified using either the KEMPEROL V210 liquid waterproofing membrane or KEMPEROL 2K-PUR for an odourless, solvent-free application.

All quantities and times are approximate and without guarantee. For color specifications, absolute RAL match can not be guaranteed.
